电源控制电缆
-
>
- 产品概述
- 产品特点
- 技术参数
产品概述
本产品用于交流额定电压uo/u 300/500v及以下的电器、仪表作电源动力的连接。
·产品标准：gb/t5023.5-2008
产品特点
电缆长期使用温度为-15℃～70℃,电缆敷设温度不低于0℃,特殊使用温度可定做。
·导体：无氧环保铜
·绝缘：聚氯乙烯绝缘料
·外护：聚氯乙烯护套料
·额定温度：70℃
·额定电压：300/300v、300/500v
技术参数
| 芯数× | 绝缘厚度 | 护套厚度 | 平 均 外 径 | 绝缘电阻 | ||
| 标称截面 | 标称值 | 标称值 | mm | 最 小 值 | 额定电压 | |
| mm2 | (mm) | (mm) | 下限 | 上 限 | (mω·km,70℃) | |
| 2×0.5 | 0.5 | 0.6 | 4.6 | 5.9 | 0.012 | 300/300v |
| 2×0.75 | 0.5 | 0.6 | 4.9 | 6.3 | 0.010 | 300/300v |
| 2×1 | 0.6 | 0.8 | 5.9 | 7.5 | 0.010 | 300/500v |
| * 2×2 | 0.7 | 0.8 | 8.0 | 9.6 | 0.010 | 300/500v |
| 2×1.5 | 0.7 | 0.8 | 6.8 | 8.6 | 0.010 | 300/500v |
| 2×2.5 | 0.8 | 1.0 | 8.4 | 10.6 | 0.009 | 300/500v |
| * 2×4 | 0.8 | 1.0 | 10.0 | 12.4 | 0.007 | 300/500v |
| 3×0.5 | 0.5 | 0.6 | 4.9 | 6.3 | 0.012 | 300/300v |
| 3×0.75 | 0.5 | 0.6 | 5.2 | 6.7 | 0.010 | 300/300v |
| 3×1 | 0.6 | 0.8 | 6.3 | 8.0 | 0.010 | 300/500v |
| 3×1.5 | 0.7 | 0.9 | 7.4 | 9.4 | 0.010 | 300/500v |
| * 3×2 | 0.7 | 0.8 | 8.7 | 10.6 | 0.010 | 300/500v |
| 3×2.5 | 0.8 | 1.1 | 9.2 | 11.4 | 0.009 | 300/500v |
| * 3×4 | 0.8 | 1.2 | 10.8 | 13.5 | 0.007 | 300/500v |
| * 3×6 | 0.8 | 1.2 | 12.4 | 14.0 | 0.007 | 300/500v |
| * 4×0.5 | 0.5 | 0.6 | 5.0 | 7.4 | 0.012 | 300/300v |
| 4×0.75 | 0.5 | 0.8 | 6.6 | 8.3 | 0.011 | 300/500v |
| 4×1 | 0.6 | 0.9 | 7.1 | 9.0 | 0.010 | 300/500v |
| 4×1.5 | 0.7 | 1.0 | 8.4 | 10.5 | 0.010 | 300/500v |
| 4×2.5 | 0.8 | 1.1 | 10.1 | 12.5 | 0.009 | 300/500v |
| * 5×0.5 | 0.5 | 0.7 | 5.6 | 8.0 | 0.012 | 300/300v |
| 5×0.75 | 0.5 | 0.9 | 7.4 | 9.3 | 0.011 | 300/500v |
| 5×1 | 0.6 | 0.9 | 7.8 | 9.8 | 0.010 | 300/500v |
| 5×1.5 | 0.7 | 1.2 | 11.2 | 13.9 | 0.009 | 300/500v |
| * 6×0.5 | 0.5 | 0.8 | 6.6 | 9.0 | 0.010 | 300/300v |
| * 6×0.75 | 0.5 | 0.8 | 6.5 | 9.6 | 0.011 | 300/500v |
| * 6×1 | 0.6 | 1.0 | 8.7 | 11.0 | 0.010 | 300/500v |
| * 6×1.5 | 0.7 | 1.1 | 9.9 | 13.3 | 0.010 | 300/500v |
| * 7×0.5 | 0.5 | 0.8 | 6.6 | 9.0 | 0.010 | 300/300v |
| * 7×0.75 | 0.5 | 0.8 | 6.5 | 9.6 | 0.011 | 300/500v |
| * 8×0.5 | 0.5 | 0.8 | 7.3 | 9.6 | 0.010 | 300/300v |
| * 8×0.75 | 0.5 | 1.0 | 7.5 | 10.6 | 0.011 | 300/500v |
| * 8×1 | 0.6 | 1.2 | 9.5 | 13.2 | 0.010 | 300/500v |
| * 8×1.5 | 0.7 | 1.2 | 10.8 | 14.2 | 0.010 | 300/500v |
| * 10×0.5 | 0.5 | 0.8 | 8.7 | 11.0 | 0.010 | 300/300v |
| * 10×0.75 | 0.5 | 1.0 | 9.0 | 13.2 | 0.011 | 300/500v |
| * 10×1 | 0.6 | 1.2 | 11.7 | 14.5 | 0.010 | 300/500v |
| * 12×0.5 | 0.5 | 0.8 | 9.0 | 11.4 | 0.010 | 300/300v |
