电源控制电缆
-
>
- 产品概述
- 产品特点
- 技术参数
产品概述
本产品适用于额定电压300/300v及以下的电器、动力、照明和自动化装置内部安装布线
·产品标准：gb/t8734.4-2012
产品特点
电缆长期使用温度为-15℃～70℃,电缆敷设温度不低于0℃,特殊使用温度可定做。
·导体：无氧环保铜
·绝缘：聚氯乙烯绝缘料
·外护：聚氯乙烯护套料
·额定温度：70℃
·额定电压：300/300v
技术参数
| 芯数× | 导体中单线 | 绝缘厚度 | 护套厚度 | 平 均 外 径 | 20℃时导体电阻最大值 | 绝缘电阻 | ||
| 标称截面 | 最大直径 | 标称值 | 标称值 | mm | ω/km | 最 小 值 | ||
| mm2 | (mm) | (mm) | (mm) | 下限 | 上 限 | 铜芯 | 镀锡铜芯 | (mω·km,70℃) |
| 2×0.12 | 0.16 | 0.4 | 0.6 | 3.3 | 4.3 | 158 | 163 | 0.016 |
| 2×0.2 | 0.16 | 0.4 | 0.6 | 3.6 | 4.7 | 92.3 | 95 | 0.014 |
| 2×0.3 | 0.16 | 0.5 | 0.6 | 4.1 | 5.3 | 69.2 | 71.2 | 0.014 |
| 2×0.4 | 0.16 | 0.5 | 0.6 | 4.4 | 5.7 | 48.2 | 49.6 | 0.013 |
| 3×0.12 | 0.16 | 0.4 | 0.6 | 3.4 | 4.5 | 158 | 163 | 0.016 |
| 3×0.2 | 0.16 | 0.4 | 0.6 | 3.8 | 4.9 | 92.3 | 95 | 0.014 |
| 3×0.3 | 0.16 | 0.5 | 0.6 | 4.4 | 5.7 | 69.2 | 71.2 | 0.014 |
| 3×0.4 | 0.16 | 0.5 | 0.6 | 4.7 | 6 | 48.2 | 49.6 | 0.013 |
| 4×0.12 | 0.16 | 0.4 | 0.6 | 3.8 | 4.9 | 158 | 163 | 0.016 |
| 4×0.2 | 0.16 | 0.4 | 0.6 | 4.2 | 5.4 | 92.3 | 95 | 0.014 |
| 4×0.3 | 0.16 | 0.5 | 0.6 | 4.8 | 6.2 | 69.2 | 71.2 | 0.014 |
| 4×0.4 | 0.16 | 0.5 | 0.6 | 5.1 | 6.6 | 48.2 | 49.6 | 0.013 |
| 5×0.12 | 0.16 | 0.4 | 0.6 | 4.1 | 5.3 | 158 | 163 | 0.016 |
| 5×0.2 | 0.16 | 0.4 | 0.6 | 4.5 | 5.8 | 92.3 | 95 | 0.014 |
| 5×0.3 | 0.16 | 0.5 | 0.6 | 5.3 | 6.7 | 69.2 | 71.2 | 0.014 |
| 5×0.4 | 0.16 | 0.5 | 0.6 | 5.6 | 7.2 | 48.2 | 49.6 | 0.013 |
| 6～7×0.12 | 0.16 | 0.4 | 0.6 | 4.4 | 5.7 | 158 | 163 | 0.016 |
| 6～7×0.2 | 0.16 | 0.4 | 0.6 | 4.9 | 6.3 | 92.3 | 95 | 0.014 |
| 6～7×0.3 | 0.16 | 0.5 | 0.6 | 5.7 | 7.3 | 69.2 | 71.2 | 0.014 |
| 6～7×0.4 | 0.16 | 0.5 | 0.6 | 6.2 | 7.8 | 48.2 | 49.6 | 0.013 |
| 10×0.12 | 0.16 | 0.4 | 0.6 | 5.7 | 7.2 | 158 | 163 | 0.016 |
| 10×0.2 | 0.16 | 0.4 | 0.6 | 6.3 | 8 | 92.3 | 95 | 0.014 |
| 10×0.3 | 0.16 | 0.5 | 0.8 | 7.8 | 9.7 | 69.2 | 71.2 | 0.014 |
| 10×0.4 | 0.16 | 0.5 | 0.8 | 8.3 | 10.4 | 48.2 | 49.6 | 0.013 |
| 12×0.12 | 0.16 | 0.4 | 0.6 | 5.8 | 7.4 | 158 | 163 | 0.016 |
| 12×0.2 | 0.16 | 0.4 | 0.6 | 6.5 | 8.2 | 92.3 | 95 | 0.014 |
| 12×0.3 | 0.16 | 0.5 | 0.8 | 8 | 10.1 | 69.2 | 71.2 | 0.014 |
| 12×0.4 | 0.16 | 0.5 | 0.8 | 8.6 | 10.8 | 48.2 | 49.6 | 0.013 |
| 14×0.12 | 0.16 | 0.4 | 0.6 | 6.1 | 7.8 | 158 | 163 | 0.016 |
| 14×0.2 | 0.16 | 0.4 | 0.8 | 7.2 | 9.1 | 92.3 | 95 | 0.014 |
| 14×0.3 | 0.16 | 0.5 | 0.8 | 8.4 | 10.6 | 69.2 | 71.2 | 0.014 |
| 14×0.4 | 0.16 | 0.5 | 0.8 | 9.1 | 11.3 | 48.2 | 49.6 | 0.013 |
| 16×0.12 | 0.16 | 0.4 | 0.6 | 6.5 | 8.2 | 158 | 163 | 0.016 |
| 16×0.2 | 0.16 | 0.4 | 0.8 | 7.6 | 9.6 | 92.3 | 95 | 0.014 |
| 16×0.3 | 0.16 | 0.5 | 0.8 | 8.9 | 11.1 | 69.2 | 71.2 | 0.014 |
| 16×0.4 | 0.16 | 0.5 | 0.8 | 9.6 | 11.9 | 48.2 | 49.6 | 0.013 |
| 19×0.12 | 0.16 | 0.4 | 0.8 | 7.2 | 9.1 | 158 | 163 | 0.016 |
| 19×0.2 | 0.16 | 0.4 | 0.8 | 8.1 | 10.1 | 92.3 | 95 | 0.014 |
| 19×0.3 | 0.16 | 0.5 | 0.8 | 9.4 | 11.7 | 69.2 | 71.2 | 0.014 |
| 19×0.4 | 0.16 | 0.5 | 0.8 | 10.1 | 12.6 | 48.2 | 49.6 | 0.013 |
| 24×0.12 | 0.16 | 0.4 | 0.8 | 8.4 | 10.6 | 158 | 163 | 0.016 |
| 24×0.2 | 0.16 | 0.4 | 0.8 | 9.4 | 11.7 | 92.3 | 95 | 0.014 |
| 24×0.3 | 0.16 | 0.5 | 1 | 11.4 | 14.2 | 69.2 | 71.2 | 0.014 |
| 24×0.4 | 0.16 | 0.5 | 1 | 12.3 | 15.2 | 48.2 | 49.6 | 0.013 |
