电源控制电缆
-
>
-
>
-
>
-
>
- 产品概述
- 产品特点
- 技术参数
产品概述
本产品适用于交流额定电压u 0/u为450/750v及以下配电装置中作电器仪表的接线。
执行标准：gb/t 9330.2-2008
产品特点
1、电缆长期使用温度为-15℃～70℃。
2、电缆敷设温度不低于0℃，特殊使用温度可定做。
3、导体：99.996%无氧软铜丝。
4、绝缘：70℃国标聚氯乙烯。
5、屏蔽层：99.996%无氧软铜丝编织，编织密度65%～80%（kvvp型）。
6、护套：70℃国标聚氯乙烯。
技术参数
芯数×标称截面 mm2 | 导体种类 | 绝缘厚度mm | kvvp型屏蔽密度 % | 外护套度 mm | 平均近似外径尺寸 mm | 70℃时绝缘电阻 最小值 mω·km | |
kvv型 | kvvp型 | ||||||
2×0.75 | 1 | 0.6 | 65~80 | 1.2 | 7.74 | — | 0.012 |
2×0.75 | 2 | 0.6 | 65~80 | 1.2 | 8.02 | 8.62 | 0.014 |
2×1.0 | 1 | 0.6 | 65~80 | 1.2 | 8.06 | — | 0.011 |
2×1.0 | 2 | 0.6 | 65~80 | 1.2 | 8.38 | 8.98 | 0.013 |
2×1.5 | 1 | 0.7 | 65~80 | 1.2 | 8.96 | — | 0.011 |
2×1.5 | 2 | 0.7 | 65~80 | 1.2 | 9.32 | 9.92 | 0.012 |
2×2.5 | 1 | 0.8 | 65~80 | 1.2 | 10.16 | — | 0.010 |
2×2.5 | 2 | 0.8 | 65~80 | 1.2 | 10.68 | 11.28 | 0.009 |
2×4 | 1 | 0.8 | 65~80 | 1.2 | 11.1 | — | 0.0077 |
2×4 | 2 | 0.8 | 65~80 | 1.2 | 11.7 | 13.1 | 0.0085 |
2×6 | 1 | 0.8 | 65~80 | 1.5 | 12.12 | — | 0.0070 |
2×6 | 2 | 0.8 | 65~80 | 1.5 | 12.84 | 14.24 | 0.0065 |
2×10 | 2 | 1.0 | 65~80 | 1.5 | 15.5 | 16.9 | 0.0065 |
3×0.75 | 1 | 0.6 | 65~80 | 1.2 | 8.07 | — | 0.012 |
3×0.75 | 2 | 0.6 | 65~80 | 1.2 | 8.38 | 8.98 | 1.014 |
3×1.0 | 1 | 0.6 | 65~80 | 1.2 | 8.42 | — | 0.011 |
3×1.0 | 2 | 0.6 | 65~80 | 1.2 | 8.76 | 9.36 | 0.013 |
3×1.5 | 1 | 0.7 | 65~80 | 1.2 | 9.39 | — | 0.011 |
3×1.5 | 2 | 0.7 | 65~80 | 1.2 | 9.78 | 10.38 | 0.012 |
3×2.5 | 1 | 0.8 | 65~80 | 1.2 | 10.68 | — | 0.010 |
3×2.5 | 2 | 0.8 | 65~80 | 1.2 | 11.24 | 11.84 | 0.009 |
3×4 | 1 | 0.8 | 65~80 | 1.2 | 11.69 | — | 0.0077 |
3×4 | 2 | 0.8 | 65~80 | 1.2 | 12.34 | 13.74 | 0.0085 |
3×6 | 1 | 0.8 | 65~80 | 1.5 | 13.39 | — | 0.0070 |
3×6 | 2 | 0.8 | 65~80 | 1.5 | 14.17 | 14.97 | 0.0065 |
3×10 | 2 | 1.0 | 65~80 | 1.5 | 17.03 | 17.83 | 0.0065 |
4×0.75 | 1 | 0.6 | 65~80 | 1.2 | 8.64 | — | 0.012 |
4×0.75 | 2 | 0.6 | 65~80 | 1.2 | 8.98 | 9.58 | 0.014 |
4×1.0 | 1 | 0.6 | 65~80 | 1.2 | 9.02 | — | 0.011 |
4×1.0 | 2 | 0.6 | 65~80 | 1.2 | 9.41 | 10.01 | 0.013 |
4×1.5 | 1 | 0.7 | 65~80 | 1.2 | 10.11 | — | 0.011 |
4×1.5 | 2 | 0.7 | 65~80 | 1.2 | 10.55 | 11.15 | 0.012 |
4×2.5 | 1 | 0.8 | 65~80 | 1.2 | 11.56 | — | 0.010 |
4×2.5 | 2 | 0.8 | 65~80 | 1.2 | 12.19 | 13.59 | 0.009 |
4×4 | 1 | 0.8 | 65~80 | 1.5 | 13.29 | — | 0.0077 |
4×4 | 2 | 0.8 | 65~80 | 1.5 | 14.02 | 14.82 | 0.0085 |
4×6 | 1 | 0.8 | 65~80 | 1.5 | 14.53 | — | 0.0070 |
4×6 | 2 | 0.8 | 65~80 | 1.5 | 15.39 | 16.19 | 0.0065 |
4×10 | 2 | 1.0 | 65~80 | 1.7 | 18.60 | 19.80 | 0.0065 |
5×0.75 | 1 | 0.6 | 65~80 | 1.2 | 9.26 | — | 0.012 |
5×0.75 | 2 | 0.6 | 65~80 | 1.2 | 9.64 | 10.24 | 0.014 |
5×1.0 | 1 | 0.6 | 65~80 | 1.2 | 9.69 | — | 0.011 |
5×1.0 | 2 | 0.6 | 65~80 | 1.2 | 10.12 | 10.72 | 0.013 |
5×1.5 | 1 | 0.7 | 65~80 | 1.2 | 10.91 | — | 0.011 |
5×1.5 | 2 | 0.7 | 65~80 | 1.2 | 11.39 | 11.99 | 0.012 |
5×2.5 | 1 | 0.8 | 65~80 | 1.5 | 13.13 | — | 0.010 |
5×2.5 | 2 | 0.8 | 65~80 | 1.5 | 13.83 | 14.63 | 0.009 |
5×4 | 1 | 0.8 | 65~80 | 1.5 | 14.40 | — | 0.0077 |
5×4 | 2 | 0.8 | 65~80 | 1.5 | 15.21 | 16.01 | 0.0085 |
5×6 | 1 | 0.8 | 65~80 | 1.5 | 15.77 | — | 0.0070 |
5×6 | 2 | 0.8 | 65~80 | 1.5 | 16.74 | 17.54 | 0.0065 |
5×10 | 2 | 1.0 | 65~80 | 1.7 | 20.74 | 21.54 | 0.0065 |
7×0.75 | 1 | 0.6 | 65~80 | 1.2 | 9.91 | — | 0.012 |
7×0.75 | 2 | 0.6 | 65~80 | 1.2 | 10.33 | 10.93 | 0.014 |
7×1.0 | 1 | 0.6 | 65~80 | 1.2 | 10.39 | — | 0.011 |
7×1.0 | 2 | 0.6 | 65~80 | 1.2 | 10.87 | 11.47 | 0.013 |
7×1.5 | 1 | 0.7 | 65~80 | 1.2 | 11.79 | — | 0.011 |
7×1.5 | 2 | 0.7 | 65~80 | 1.2 | 12.28 | 13.48 | 0.012 |
7×2.5 | 1 | 0.8 | 65~80 | 1.5 | 14.14 | — | 0.010 |
7×2.5 | 2 | 0.8 | 65~80 | 1.5 | 14.60 | 15.60 | 0.010 |
8×2.5 | 1 | 0.8 | 65~80 | 1.5 | 14.92 | — | 0.010 |
8×2.5 | 2 | 0.8 | 65~80 | 1.5 | 15.72 | 16.55 | 0.009 |
8×4 | 1 | 0.8 | 65~80 | 1.5 | 16.43 | — | 0.0077 |
8×4 | 2 | 0.8 | 65~80 | 1.5 | 17.4 | 18.6 | 0.0085 |
8×6 | 1 | 0.8 | 65~80 | 1.7 | 18.48 | — | 0.0070 |
8×6 | 2 | 0.8 | 65~80 | 1.7 | 19.64 | 20.44 | 0.0065 |
8×10 | 2 | 1.0 | 65~80 | 1.7 | 23.94 | 24.94 | 0.0065 |
10×0.75 | 1 | 0.6 | 65~80 | 1.2 | 12.08 | — | 0.012 |
10×0.75 | 2 | 0.6 | 65~80 | 1.2 | 12.64 | 14.04 | 0.014 |
10×1.0 | 1 | 0.6 | 65~80 | 1.5 | 13.32 | — | 0.011 |
10×1.0 | 2 | 0.6 | 65~80 | 1.5 | 13.96 | 14.76 | 0.013 |
10×1.5 | 1 | 0.7 | 65~80 | 1.5 | 15.12 | — | 0.011 |
10×1.5 | 2 | 0.7 | 65~80 | 1.5 | 15.84 | 16.64 | 0.012 |
10×2.5 | 1 | 0.8 | 65~80 | 1.5 | 17.52 | — | 0.010 |
10×2.5 | 2 | 0.8 | 65~80 | 1.5 | 18.56 | 19.36 | 0.009 |
10×4 | 1 | 0.8 | 65~80 | 1.7 | 19.8 | — | 0.0077 |
10×4 | 2 | 0.8 | 65~80 | 1.7 | 21 | 21.8 | 0.0085 |
10×6 | 1 | 0.8 | 65~80 | 1.7 | 21.84 | — | 0.0070 |
10×6 | 2 | 0.8 | 65~80 | 1.7 | 23.28 | 24.28 | 0.0065 |
10×10 | 2 | 1.0 | 65~80 | 1.7 | 28.6 | 29.6 | 0.0065 |
12×0.75 | 1 | 0.6 | 65~80 | 1.5 | 13.01 | — | 0.012 |
12×0.75 | 2 | 0.6 | 65~80 | 1.5 | 13.6 | 14.40 | 0.014 |
12×1.0 | 1 | 0.6 | 65~80 | 1.5 | 13.68 | — | 0.011 |
12×1.0 | 2 | 0.6 | 65~80 | 1.5 | 14.34 | 15.14 | 0.013 |
12×1.5 | 1 | 0.7 | 65~80 | 1.5 | 15.55 | — | 0.011 |
12×1.5 | 2 | 0.7 | 65~80 | 1.5 | 16.3 | 17.1 | 0.012 |
12×2.5 | 1 | 0.8 | 65~80 | 1.5 | 18.04 | — | 0.010 |
12×2.5 | 2 | 0.8 | 65~80 | 1.5 | 19.12 | 20.32 | 0.009 |
12×4 | 1 | 0.8 | 65~80 | 1.7 | 20.39 | — | 0.0077 |
12×4 | 2 | 0.8 | 65~80 | 1.7 | 21.64 | 22.44 | 0.0085 |
12×6 | 1 | 0.8 | 65~80 | 1.7 | 22.51 | — | 0.0070 |
12×6 | 2 | 0.8 | 65~80 | 1.7 | 24.01 | 25.01 | 0.0065 |
14×0.75 | 1 | 0.6 | 65~80 | 1.5 | 13.58 | — | 0.012 |
14×0.75 | 2 | 0.6 | 65~80 | 1.5 | 14.20 | 15 | 0.014 |
14×1.0 | 1 | 0.6 | 65~80 | 1.5 | 14.28 | — | 0.011 |
14×1.0 | 2 | 0.6 | 65~80 | 1.5 | 15.99 | 16.79 | 0.013 |
14×1.5 | 1 | 0.7 | 65~80 | 1.5 | 16.27 | — | 0.011 |
14×1.5 | 2 | 0.7 | 65~80 | 1.5 | 17.07 | 17.87 | 0.012 |
14×2.5 | 1 | 0.8 | 65~80 | 1.5 | 18.92 | — | 0.010 |
14×2.5 | 2 | 0.8 | 65~80 | 1.5 | 20.07 | 21.27 | 0.009 |
14×4 | 1 | 0.8 | 65~80 | 1.7 | 21.39 | — | 0.0077 |
14×4 | 2 | 0.8 | 65~80 | 1.7 | 22.72 | 23.52 | 0.0085 |
14×6 | 1 | 0.8 | 65~80 | 1.7 | 23.65 | — | 0.0070 |
14×6 | 2 | 0.8 | 65~80 | 1.7 | 25.23 | 26.23 | 0.0065 |
16×0.75 | 1 | 0.6 | 65~80 | 1.5 | 14.20 | — | 0.012 |
16×0.75 | 2 | 0.6 | 65~80 | 1.5 | 14.86 | 15.66 | 0.014 |
16×1.0 | 1 | 0.6 | 65~80 | 1.5 | 14.95 | — | 0.011 |
16×1.0 | 2 | 0.6 | 65~80 | 1.5 | 15.70 | 16.50 | 0.013 |
16×1.5 | 1 | 0.7 | 65~80 | 1.5 | 17.07 | — | 0.011 |
16×1.5 | 2 | 0.7 | 65~80 | 1.5 | 17.91 | 18.71 | 0.012 |
16×2.5 | 1 | 0.8 | 65~80 | 1.7 | 20.29 | — | 0.010 |
16×2.5 | 2 | 0.8 | 65~80 | 1.7 | 21.57 | 22.31 | 0.009 |
19×0.75 | 1 | 0.6 | 65~80 | 1.5 | 14.85 | — | 0.012 |
19×0.75 | 2 | 0.6 | 65~80 | 1.5 | 15.55 | 16.35 | 0.014 |
19×1.0 | 1 | 0.6 | 65~80 | 1.5 | 15.65 | — | 0.011 |
19×1.0 | 2 | 0.6 | 65~80 | 1.5 | 16.45 | 17.25 | 0.013 |
19×1.5 | 1 | 0.7 | 65~80 | 1.5 | 17.9 | — | 0.011 |
19×1.5 | 2 | 0.7 | 65~80 | 1.5 | 18.8 | 20 | 0.012 |
19×2.5 | 1 | 0.8 | 65~80 | 1.7 | 21.3 | — | 0.010 |
19×2.5 | 2 | 0.8 | 65~80 | 1.7 | 22.6 | 23.4 | 0.009 |
24×0.75 | 1 | 0.6 | 65~80 | 1.5 | 17.02 | — | 0.012 |
24×0.75 | 2 | 0.6 | 65~80 | 1.5 | 17.86 | 18.66 | 0.014 |
24×1.0 | 1 | 0.6 | 65~80 | 1.5 | 17.98 | — | 0.011 |
24×1.0 | 2 | 0.6 | 65~80 | 1.5 | 18.94 | 20.14 | 0.013 |
24×1.5 | 1 | 0.7 | 65~80 | 1.5 | 20.68 | — | 0.011 |
24×1.5 | 2 | 0.7 | 65~80 | 1.5 | 22.16 | 22.96 | 0.012 |
24×2.5 | 1 | 0.8 | 65~80 | 1.7 | 24.68 | — | 0.010 |
24×2.5 | 2 | 0.8 | 65~80 | 1.7 | 26.24 | 27.24 | 0.009 |
27×0.75 | 1 | 0.6 | 65~80 | 1.5 | 17.35 | 0.012 | |
27×0.75 | 2 | 0.6 | 65~80 | 1.5 | 18.26 | 19.06 | 0.014 |
27×1.0 | 1 | 0.6 | 65~80 | 1.5 | 18.34 | — | 0.011 |
27×1.0 | 2 | 0.6 | 65~80 | 1.5 | 19.32 | 20.52 | 0.013 |
27×1.5 | 1 | 0.7 | 65~80 | 1.7 | 21.51 | — | 0.011 |
27×1.5 | 2 | 0.7 | 65~80 | 1.7 | 22.62 | 23.42 | 0.012 |
27×2.5 | 1 | 0.8 | 65~80 | 1.7 | 25.2 | — | 0.010 |
27×2.5 | 2 | 0.8 | 65~80 | 1.7 | 26.8 | 27.8 | 0.009 |
30×0.75 | 1 | 0.6 | 65~80 | 1.5 | 17.92 | — | 0.012 |
30×0.75 | 2 | 0.6 | 65~80 | 1.5 | 18.82 | 20.02 | 0.014 |
30×1.0 | 1 | 0.6 | 65~80 | 1.7 | 19.34 | — | 0.011 |
30×1.0 | 2 | 0.6 | 65~80 | 1.7 | 20.37 | 21.17 | 0.013 |
30×1.5 | 1 | 0.7 | 65~80 | 1.7 | 22.23 | — | 0.011 |
30×1.5 | 2 | 0.7 | 65~80 | 1.7 | 23.39 | 24.39 | 0.012 |
30×2.5 | 1 | 0.8 | 65~80 | 1.7 | 26.08 | — | 0.010 |
30×2.5 | 2 | 0.8 | 65~80 | 1.7 | 27.75 | 28.75 | 0.009 |
37×0.75 | 1 | 0.6 | 65~80 | 1.7 | 19.59 | — | 0.012 |
37×0.75 | 2 | 0.6 | 65~80 | 1.7 | 20.57 | 21.37 | 0.014 |
37×1.0 | 1 | 0.6 | 65~80 | 1.7 | 20.71 | — | 0.011 |
37×1.0 | 2 | 0.6 | 65~80 | 1.7 | 21.83 | 22.63 | 0.013 |
37×1.5 | 1 | 0.7 | 65~80 | 1.7 | 23.86 | — | 0.011 |
37×1.5 | 2 | 0.7 | 65~80 | 1.7 | 25.12 | 26.12 | 0.012 |
37×2.5 | 1 | 0.8 | 65~80 | 1.7 | 28.06 | — | 0.010 |
37×2.5 | 2 | 0.8 | 65~80 | 1.7 | 29.88 | 31.48 | 0.009 |
