电源控制电缆
- 产品概述
- 产品特点
- 技术参数
产品概述
本产品适用于交流额定电压u 0/u为300/500v、450/750v及以下动力装置作固定布线(敷设)用。
执行标准:jb/t 8734.2-2012、gb/t 5023.3-2008
产品特点
1、电缆长期使用温度为-15℃~70℃。
2、电缆敷设温度不低于0℃,特殊使用温度可定做。
3、导体:99.996%无氧软铜丝。
4、绝缘:70℃国标聚氯乙烯。
5、护套:70℃国标聚氯乙烯(有护套型)。
技术参数
bv型300/500v铜芯聚氯乙烯绝缘电线
执行标准:jb/t 8734.2-2012
导体标称截面 mm2 | 绞合导体最少根数 | 绝缘厚度 mm | 平均外径 上限 mm | 20℃时导体电阻最大值 ω/km | 70℃时绝缘电阻最小值 mω·km | |
铜芯 | 镀锡铜芯 | |||||
0.75 | 7 | 0.6 | 2.60 | 24.5 | 24.8 | 0.014 |
1.0 | 7 | 0.6 | 2.80 | 18.1 | 18.2 | 0.013 |
60227 iec 05(bv) 型300/500v,70℃单芯实心无护套电缆
执行标准:gb/t 5023.3-2008
导体标称截面 mm2 | 绝缘厚度 mm | 平均外径上限 mm | 20℃时导体电阻 最大值 ω/km | 70℃时绝缘电阻 最小值 mω·km |
0.5 | 0.6 | 2.40 | 36.0 | 0.015 |
0.75 | 0.6 | 2.60 | 24.5 | 0.012 |
1.0 | 0.6 | 2.80 | 18.1 | 0.011 |
60227 iec 01(bv) 型450/750v,一般用途单芯硬导体无护套电缆
执行标准-:gb/t 5023.3-2008
导体标称截面 mm2 | 导体种类 | 绝缘厚度 | 平均外径上限 mm | 20℃时导体电阻最大值 | 70℃时绝缘电阻 最小值 mω·km |
1.5 | 1 | 0.7 | 3.3 | 12.1 | 0.011 |
2 | 3.4 | 0.010 | |||
2.5 | 1 | 0.8 | 3.9 | 7.41 | 0.010 |
2 | 4.2 | 0.009 | |||
4 | 1 | 0.8 | 4.4 | 4.61 | 0.0085 |
2 | 4.8 | 0.0077 | |||
6 | 1 | 0.8 | 4.9 | 3.08 | 0.0070 |
2 | 5.4 | 0.0065 | |||
10 | 1 | 1.0 | 6.4 | 1.83 | 0.0070 |
2 | 6.8 | 0.0065 | |||
16 | 2 | 1.0 | 8.0 | 1.15 | 0.0050 |
25 | 2 | 1.2 | 9.8 | 0.727 | 0.0050 |
35 | 2 | 1.2 | 11.0 | 0.524 | 0.0040 |
50 | 2 | 1.4 | 13.0 | 0.387 | 0.0045 |
70 | 2 | 1.4 | 15.0 | 0.268 | 0.0035 |
95 | 2 | 1.6 | 17.0 | 0.193 | 0.0035 |
120 | 2 | 1.6 | 19.0 | 0.153 | 0.0032 |
150 | 2 | 1.8 | 21.0 | 0.124 | 0.0032 |
185 | 2 | 2.0 | 23.5 | 0.0991 | 0.0032 |
bvr型450/750v铜芯聚氯乙烯绝缘软电缆
执行标准:jb/t 8734.2-2012
导体标称截面 mm2 | 绞合导体最少根数 | 绝缘厚度 mm | 平均外径上限 mm | 20℃时导体电阻最大值 ω/km | 70℃时绝缘电阻最小值 mω·km | |
铜芯 | 镀锡铜芯 | |||||
2.5 | 19 | 0.8 | 4.1 | 7.41 | 7.56 | 0.010 |
4 | 19 | 0.8 | 4.8 | 4.61 | 4.70 | 0.009 |
6 | 19 | 0.8 | 5.3 | 3.08 | 3.11 | 0.0084 |
10 | 49 | 1.0 | 6.8 | 1.83 | 1.84 | 0.0072 |
16 | 49 | 1.0 | 8.1 | 1.15 | 1.16 | 0.0062 |
25 | 98 | 1.2 | 10.2 | 0.727 | 0.734 | 0.0058 |
35 | 133 | 1.2 | 11.7 | 0.524 | 0.529 | 0.0052 |
50 | 133 | 1.4 | 13.9 | 0.387 | 0.391 | 0.0051 |
70 | 189 | 1.4 | 16.0 | 0.268 | 0.270 | 0.0045 |
bvvb型300/500v铜芯聚氯乙烯绝缘聚氯乙烯护套扁型电缆
执行标准:jb/t 8734.2-2012
芯数×标称截面 mm2 | 绞合导体最少根数 | 绞合导体最少根数mm | 护套厚度 mm | 平均外径尺寸 mm | 20℃时导体电阻 最大值 ω/km | 70℃时绝缘电阻 最小值 mω·km | ||
下限 | 上限 | 铜芯 | 镀锡铜芯 | |||||
2×0.75 | 1 | 0.6 | 0.9 | 3.8×5.9 | 4.6×7.1 | 24.5 | 24.8 | 0.012 |
2×1.0 | 1 | 0.6 | 0.9 | 3.9×6.1 | 4.8×7.4 | 18.1 | 18.2 | 0.011 |
2×1.5 | 1 | 0.7 | 0.9 | 4.4×7.0 | 5.8×8.5 | 12.1 | 12.2 | 0.011 |
2×2.5 | 1 | 0.8 | 1.0 | 5.1×8.4 | 6.2×10.1 | 7.41 | 7.56 | 0.010 |
2×4 | 1 | 0.8 | 1.0 | 5.6×9.2 | 6.7×11.1 | 4.61 | 4.70 | 0.0085 |
2×4 | 7 | 0.8 | 1.0 | 5.7×9.5 | 6.9×11.5 | 4.61 | 4.70 | 0.008 |
2×6 | 1 | 0.8 | 1.1 | 6.2×10.4 | 7.5×12.5 | 3.08 | 3.11 | 0.0070 |
2×6 | 7 | 0.8 | 1.1 | 6.4×10.8 | 7.8×13.0 | 3.08 | 3.11 | 0.0065 |
3×0.75 | 1 | 0.6 | 0.9 | 3.8×7.9 | 4.6×9.6 | 24.5 | 24.8 | 0.012 |
3×1.0 | 1 | 0.6 | 0.9 | 3.9×8.4 | 4.8×10.1 | 18.1 | 18.2 | 0.011 |
3×1.5 | 1 | 0.7 | 0.9 | 4.4×9.6 | 5.3×11.7 | 12.1 | 12.2 | 0.011 |
3×2.5 | 1 | 0.8 | 1.0 | 5.1×11.6 | 6.2×14.0 | 7.41 | 7.56 | 0.010 |
3×4 | 1 | 0.8 | 1.1 | 5.8×13.1 | 7.0×15.8 | 4.61 | 4.70 | 0.0085 |
3×4 | 7 | 0.8 | 1.1 | 5.9×13.5 | 7.1×16.3 | 4.61 | 4.70 | 0.008 |
3×6 | 1 | 0.8 | 1.1 | 6.2×14.5 | 7.5×17.5 | 3.08 | 3.11 | 0.0070 |
3×6 | 7 | 0.8 | 1.1 | 6.4×15.1 | 7.8×18.2 | 3.08 | 3.11 | 0.0065 |
60227 iec 10(bvv)型300/500v轻型聚氯乙烯护套电缆
执行标准:gb/t 5023.4-2008
芯数×标称截面mm2 | 导体种类 | 绝缘厚度mm | 内护套 近似厚度 mm | 外护套度 mm | 平均外径 mm | 20℃时导体电阻 最大值ω/km | 70℃时 绝缘电阻 最小值 mω·km | |
下限 | 上限 | |||||||
2×1.5 | 1 | 0.7 | 0.4 | 1.2 | 7.6 | 10.0 | 12.1 | 0.011 |
2 | 0.7 | 0.4 | 1.2 | 7.8 | 10.5 | 12.1 | 0.010 | |
2×2.5 | 1 | 0.8 | 0.4 | 1.2 | 8.6 | 11.5 | 7.41 | 0.010 |
2 | 0.8 | 0.4 | 1.2 | 9.0 | 12.0 | 7.41 | 0.009 | |
2×4 | 1 | 0.8 | 0.4 | 1.2 | 9.6 | 12.5 | 4.61 | 0.0085 |
2 | 0.8 | 0.4 | 1.2 | 10.0 | 13.0 | 4.61 | 0.0077 | |
2×6 | 1 | 0.8 | 0.4 | 1.2 | 10.5 | 13.5 | 3.08 | 0.0070 |
2 | 0.8 | 0.4 | 1.2 | 11.0 | 14.0 | 3.08 | 0.0065 | |
2×10 | 1 | 1.0 | 0.6 | 1.4 | 13.0 | 16.5 | 1.83 | 0.0070 |
2 | 1.0 | 0.6 | 1.4 | 13.5 | 17.5 | 1.83 | 0.0065 | |
2×16 | 2 | 1.0 | 0.6 | 1.4 | 15.5 | 20.0 | 1.15 | 0.0052 |
2×25 | 2 | 1.2 | 0.8 | 1.4 | 18.5 | 24.0 | 0.727 | 0.0050 |
2×35 | 2 | 1.2 | 1.0 | 1.6 | 21.0 | 27.5 | 0.524 | 0.0044 |
3×1.5 | 1 | 0.7 | 0.4 | 1.2 | 8.0 | 10.5 | 12.1 | 0.011 |
2 | 0.7 | 0.4 | 1.2 | 8.2 | 11.0 | 12.1 | 0.010 | |
3×2.5 | 1 | 0.8 | 0.4 | 1.2 | 9.2 | 12.0 | 7.41 | 0.010 |
2 | 0.8 | 0.4 | 1.2 | 9.4 | 12.5 | 7.41 | 0.009 | |
3×4 | 1 | 0.8 | 0.4 | 1.2 | 10.0 | 13.0 | 4.61 | 0.0085 |
2 | 0.8 | 0.4 | 1.2 | 10.5 | 13.5 | 4.61 | 0.0077 | |
3×6 | 1 | 0.8 | 0.4 | 1.4 | 11.5 | 14.5 | 3.08 | 0.0070 |
2 | 0.8 | 0.4 | 1.2 | 12.0 | 15.5 | 3.08 | 0.0065 | |
3×10 | 1 | 1.0 | 0.6 | 1.4 | 14.0 | 17.5 | 1.83 | 0.0070 |
2 | 1.0 | 0.6 | 1.4 | 14.5 | 19.0 | 1.83 | 0.0065 | |
3×16 | 2 | 1.0 | 0.8 | 1.4 | 16.5 | 21.5 | 1.15 | 0.0052 |
3×25 | 2 | 1.2 | 0.8 | 1.6 | 20.5 | 26.0 | 0.727 | 0.0050 |
3×35 | 2 | 1.2 | 1.0 | 1.6 | 22.0 | 29.0 | 0.524 | 0.0044 |
4×1.5 | 1 | 0.7 | 0.4 | 1.2 | 8.6 | 11.5 | 12.1 | 0.011 |
2 | 0.7 | 0.4 | 1.2 | 9.0 | 12.0 | 12.1 | 0.010 | |
4×2.5 | 1 | 0.8 | 0.4 | 1.2 | 10.0 | 13.0 | 7.41 | 0.010 |
2 | 0.8 | 0.4 | 1.2 | 10.0 | 13.5 | 7.41 | 0.009 | |
4×4 | 1 | 0.8 | 0.4 | 1.4 | 11.5 | 14.5 | 4.61 | 0.0085 |
2 | 0.8 | 0.4 | 1.2 | 12.0 | 15.0 | 4.61 | 0.0077 | |
4×6 | 1 | 0.8 | 0.6 | 1.4 | 12.5 | 16.0 | 3.08 | 0.0070 |
2 | 0.8 | 0.6 | 1.4 | 13.0 | 17.0 | 3.08 | 0.0065 | |
4×10 | 1 | 1.0 | 0.6 | 1.4 | 15.5 | 19.0 | 1.83 | 0.0070 |
2 | 1.0 | 0.6 | 1.4 | 16.0 | 20.5 | 1.83 | 0.0065 | |
4×16 | 2 | 1.0 | 0.8 | 1.4 | 18.0 | 23.5 | 1.15 | 0.0052 |
4×25 | 2 | 1.2 | 1.0 | 1.6 | 22.5 | 28.5 | 0.727 | 0.0050 |
4×35 | 2 | 1.2 | 1.0 | 1.6 | 24.5 | 32.0 | 0.524 | 0.0044 |
5×1.5 | 1 | 0.7 | 0.4 | 1.2 | 9.4 | 12.0 | 12.1 | 0.011 |
2 | 0.7 | 0.4 | 1.2 | 9.8 | 12.5 | 12.1 | 0.010 | |
5×2.5 | 1 | 0.8 | 0.4 | 1.2 | 11.0 | 14.0 | 7.41 | 0.010 |
2 | 0.8 | 0.4 | 1.2 | 11.0 | 14.5 | 7.41 | 0.009 | |
5×4 | 1 | 0.8 | 0.6 | 1.4 | 12.5 | 16.0 | 4.61 | 0.0085 |
2 | 0.8 | 0.6 | 1.4 | 13.0 | 17.0 | 4.61 | 0.0077 | |
5×6 | 1 | 0.8 | 0.6 | 1.4 | 13.5 | 17.5 | 3.08 | 0.0070 |
2 | 0.8 | 0.6 | 1.4 | 14.5 | 18.5 | 3.08 | 0.0065 | |
5×10 | 1 | 1.0 | 0.6 | 1.4 | 17.0 | 21.0 | 1.83 | 0.0070 |
2 | 1.0 | 0.6 | 1.4 | 17.5 | 22.0 | 1.83 | 0.0065 | |
5×16 | 2 | 1.0 | 0.8 | 1.6 | 20.5 | 26.0 | 1.15 | 0.0052 |
4×25 | 2 | 1.2 | 1.0 | 1.6 | 24.5 | 31.5 | 0.727 | 0.0050 |
4×35 | 2 | 1.2 | 1.2 | 1.6 | 27.0 | 35.0 | 0.524 | 0.0040 |
